16’6″x65′ 2d-Plan

This is a plan for a plot that has only front side road. Not too wide, but has some length.

Bedrooms

1. Bedroom 1

• Dimensions: 9′ x 15′
• Area: 135.28 sq ft

1. Bedroom 2

• Dimensions: 9′ x 15′
• Area: 134.93 sq ft

1. Bedroom 3

• Dimensions: 15′ 6″ x 9′ 6″
• Area: 146.97 sq ft

Bathrooms

1. Bathroom 1

• Dimensions: 6′ x 4′
• Area: 23.81 sq ft

1. Bathroom 2

• Dimensions: 3′ 6″ x 4′
• Area: 14 sq ft

Other Rooms

1. Living Room

• Dimensions: 15′ 6″ x 11′
• Area: 170.39 sq ft

1. Kitchen

• Dimensions: 6′ x 19′
• Area: 114.44 sq ft

1. Hallway

• Dimensions: 5′ x 4′
• Area: 20.02 sq ft

1. Stairway

• Dimensions: 15′ 6″ x 18′ 5″
• Area: 139.08 sq ft

1. Pooja Room

• Dimensions: 9′ x 3′ 6″
• Area: 31.14 sq ft

Airflow

• The house has several points of entry and exit for air, ensuring good ventilation.
• Main entrances are through the living room (top), bedrooms (middle and bottom).
• Air can flow from the living room to the kitchen and bedrooms through doors.
• The bathrooms are strategically located for easy access from each bedroom, ensuring they are well-ventilated.

Dimensions of Rooms and Total Area

Each room’s dimensions are clearly mentioned, ensuring enough space for furniture and movement.

Total area of the house includes living spaces, bedrooms, bathrooms, kitchen, hallway, stairway, and pooja room.
